Good morning!
I want to move my AS3935 lightning detector to an ESP32, so I can ESPNow it to my base station. I found a script for ESP8266 that addresses the calibration and noise problems I’ve had- and it uses a NeoPixel, but now that I apparently have the libraries installed it’s throwing up a ton of errors that indicate I’ve been Arduinoed again.
(these are the three odd libraries:
GitHub - esp8266/Arduino: ESP8266 core for Arduino)
This is the text of the program. I would really like it if we could declare everything properly enough to work in a real IDE, and I reallyreally want it to be on an ESP32. So even if I were to successfully pick through and make the Arduino code work, I still don’t have the skills to move it to the other platform.
/*
* Kaminari
*
* Copyright (C) 2020 Richard "Shred" Körber
* https://github.com/shred/kaminari
*
* This program is free software: you can redistribute it and/or modify
* it under the terms of the GNU General Public License as published by
* the Free Software Foundation, either version 3 of the License, or
* (at your option) any later version.
*
* This program is distributed in the hope that it will be useful,
* but WITHOUT ANY WARRANTY; without even the implied warranty of
* MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the
* GNU General Public License for more details.
*/
#include <Arduino.h>
#include <SPI.h>
#include <ArduinoJson.h>
#include <ESP8266WiFi.h>
#include <WiFiClient.h>
#include <ESP8266WebServer.h>
#include <ESP8266mDNS.h>
#include <Adafruit_NeoPixel.h>
#include <PubSubClient.h>
#include "AS3935.h"
#include "Config.h"
#include "myWiFi.h"
#define SPI_CS 15 // IO15 (D8)
#define SPI_MOSI 13 // IO13 (D7)
#define SPI_MISO 12 // IO12 (D6)
#define SPI_SCK 14 // IO14 (D5)
#define AS_INT 5 // IO5 (D1)
#define NEOPIXEL 4 // IO4 (D2)
#define PORT 80
#define COLOR_CONNECTING 0x00800000
#define COLOR_CALIBRATING 0x00404000
#define COLOR_BLACK 0x00000000
#define DISTANCE_ANIMATION_TIME 5000
#define ENERGY_ANIMATION_TIME 500
#define DISTURBER_ANIMATION_TIME 1000
ConfigManager cfgMgr;
ESP8266WebServer server(PORT);
AS3935 detector(SPI_CS, AS_INT);
Adafruit_NeoPixel neopixel(1, NEOPIXEL, NEO_GRBW + NEO_KHZ800);
WiFiClient wifiClient;
PubSubClient client(MY_MQTT_SERVER_HOST, MY_MQTT_SERVER_PORT, wifiClient);
WiFiEventHandler connectedEventHandler, gotIpEventHandler, disconnectedEventHandler;
unsigned long beforeAnimation = millis();
unsigned long beforeMqttConnection = millis();
bool connected = false;
unsigned int currentColor = 0;
Lightning ledLightning;
inline static unsigned long timeDifference(unsigned long now, unsigned long past)
{
// This is actually safe from millis() overflow because all types are unsigned long!
return past > 0 ? (now - past) : 0;
}
void sendJsonResponse(ArduinoJson::JsonDocument &doc, int status = 200)
{
String json;
serializeJson(doc, json);
server.send(status, "application/json", json);
}
bool authenticated()
{
if (server.header("X-API-Key") == MY_APIKEY)
{
return true;
}
if (server.arg("api_key") == MY_APIKEY)
{
return true;
}
server.send(403);
return false;
}
void handleStatus()
{
DynamicJsonDocument doc(8192);
unsigned long now = millis();
JsonArray la = doc.createNestedArray("lightnings");
Lightning lightning;
for (int ix = 0;; ix++)
{
if (!detector.getLastLightningDetection(ix, lightning))
{
break;
}
StaticJsonDocument<200> subdoc;
subdoc["age"] = timeDifference(now, lightning.time) / 1000;
subdoc["energy"] = lightning.energy;
if (lightning.distance < 0x3F)
{
subdoc["distance"] = lightning.distance;
}
else
{
subdoc["distance"] = (char *)NULL;
}
la.add(subdoc);
}
unsigned int distance = detector.getEstimatedDistance();
if (distance < 0x3F)
{
doc["distance"] = distance;
}
else
{
doc["distance"] = (char *)NULL;
}
doc["energy"] = detector.getEnergy();
doc["noiseFloorLevel"] = detector.getNoiseFloorLevel();
doc["disturbersPerMinute"] = detector.getDisturbersPerMinute();
doc["watchdogThreshold"] = detector.getWatchdogThreshold();
doc["wifiSignalStrength"] = WiFi.RSSI();
sendJsonResponse(doc);
}
void handleSettings()
{
DynamicJsonDocument doc(1024);
doc["tuning"] = detector.getFrequency();
doc["noiseFloorLevel"] = detector.getNoiseFloorLevel();
doc["outdoorMode"] = detector.getOutdoorMode();
doc["watchdogThreshold"] = detector.getWatchdogThreshold();
doc["minimumNumberOfLightning"] = detector.getMinimumNumberOfLightning();
doc["spikeRejection"] = detector.getSpikeRejection();
doc["outdoorMode"] = detector.getOutdoorMode();
doc["statusLed"] = cfgMgr.config.ledEnabled;
doc["blueBrightness"] = cfgMgr.config.blueBrightness;
doc["disturberBrightness"] = cfgMgr.config.disturberBrightness;
sendJsonResponse(doc);
}
void handleUpdate()
{
if (authenticated())
{
bool needsClearing = false;
if (server.hasArg("watchdogThreshold"))
{
long val = String(server.arg("watchdogThreshold")).toInt();
if (val >= 0 && val <= 10)
{
cfgMgr.config.watchdogThreshold = val;
detector.setWatchdogThreshold(val);
needsClearing = true;
}
}
if (server.hasArg("minimumNumberOfLightning"))
{
long val = String(server.arg("minimumNumberOfLightning")).toInt();
if (val == 1 || val == 5 || val == 9 || val == 16)
{
cfgMgr.config.minimumNumberOfLightning = val;
detector.setMinimumNumberOfLightning(val);
}
}
if (server.hasArg("spikeRejection"))
{
long val = String(server.arg("spikeRejection")).toInt();
if (val >= 0 && val <= 11)
{
cfgMgr.config.spikeRejection = val;
detector.setSpikeRejection(val);
needsClearing = true;
}
}
if (server.hasArg("outdoorMode"))
{
bool val = String(server.arg("outdoorMode")) == "true";
cfgMgr.config.outdoorMode = val;
detector.setOutdoorMode(val);
needsClearing = true;
}
if (server.hasArg("statusLed"))
{
cfgMgr.config.ledEnabled = String(server.arg("statusLed")) == "true";
}
if (server.hasArg("blueBrightness"))
{
long val = String(server.arg("blueBrightness")).toInt();
if (val >= 0 && val <= 255)
{
cfgMgr.config.blueBrightness = val;
}
}
if (server.hasArg("disturberBrightness"))
{
long val = String(server.arg("disturberBrightness")).toInt();
if (val >= 0 && val <= 255)
{
cfgMgr.config.disturberBrightness = val;
}
}
cfgMgr.commit();
handleSettings();
if (needsClearing)
{
// clear detector statistics after changing the detector config
detector.clearStatistics();
}
}
}
void handleCalibrate()
{
if (authenticated())
{
unsigned int oldColor = currentColor;
color(COLOR_CALIBRATING);
StaticJsonDocument<200> doc;
doc["tuning"] = detector.calibrate();
sendJsonResponse(doc);
color(oldColor);
}
}
void handleClear()
{
if (authenticated())
{
detector.clearDetections();
server.send(200, "text/plain", "OK");
}
}
void handleReset()
{
if (authenticated())
{
detector.reset();
handleCalibrate();
setupDetector();
detector.clearStatistics();
}
}
void sendMqttStatus()
{
DynamicJsonDocument doc(8192);
String json;
Lightning lightning;
if (detector.getLastLightningDetection(0, lightning))
{
doc["energy"] = lightning.energy;
if (lightning.distance < 0x3F)
{
doc["distance"] = lightning.distance;
}
else
{
doc["distance"] = (char *)NULL;
}
}
else
{
doc["energy"] = (char *)NULL;
doc["distance"] = (char *)NULL;
}
doc["tuning"] = detector.getFrequency();
doc["noiseFloorLevel"] = detector.getNoiseFloorLevel();
doc["disturbersPerMinute"] = detector.getDisturbersPerMinute();
doc["watchdogThreshold"] = detector.getWatchdogThreshold();
doc["wifiSignalStrength"] = WiFi.RSSI();
serializeJson(doc, json);
if (!client.publish(MY_MQTT_TOPIC, json.c_str(), MY_MQTT_RETAIN))
{
Serial.print("Failed to send MQTT message, rc=");
Serial.println(client.state());
}
}
void setupDetector()
{
detector.setOutdoorMode(cfgMgr.config.outdoorMode);
detector.setWatchdogThreshold(cfgMgr.config.watchdogThreshold);
detector.setMinimumNumberOfLightning(cfgMgr.config.minimumNumberOfLightning);
detector.setSpikeRejection(cfgMgr.config.spikeRejection);
}
void color(unsigned int color)
{
if (color != currentColor)
{
neopixel.fill(color);
neopixel.show();
currentColor = color;
}
}
inline int limit(int v)
{
return v <= 255 ? (v >= 0 ? v : 0) : 255;
}
void updateColor(unsigned long now)
{
if (!connected)
{
color(now % 1000 <= 500 ? COLOR_CONNECTING : COLOR_BLACK);
return;
}
if (!cfgMgr.config.ledEnabled)
{
color(COLOR_BLACK);
return;
}
// Calculate blue color (noise floor level)
int blue = 0;
if (detector.isNoiseFloorLevelOutOfRange())
{
blue = now % 1000 <= 500 ? (cfgMgr.config.blueBrightness > 128 ? cfgMgr.config.blueBrightness : 128) : 0;
}
else
{
blue = detector.getNoiseFloorLevel() * cfgMgr.config.blueBrightness / (detector.getOutdoorMode() ? 2000 : 146);
}
// Calculate lightning age (white) and distance (green to red)
long red = 0;
long green = 0;
long white = 0;
if (ledLightning.time > 0 && ledLightning.distance <= 40)
{
unsigned long diff = timeDifference(now, ledLightning.time);
long distancePast = (DISTANCE_ANIMATION_TIME + ENERGY_ANIMATION_TIME) - diff;
long energyPast = ENERGY_ANIMATION_TIME - diff;
if (energyPast >= 0)
{
white = ((ledLightning.energy) * energyPast * 255) / (300000 * ENERGY_ANIMATION_TIME);
blue = 0;
}
else if (distancePast >= 0)
{
green = ((ledLightning.distance) * distancePast * 255) / (40 * DISTANCE_ANIMATION_TIME);
red = ((40 - ledLightning.distance) * distancePast * 255) / (40 * DISTANCE_ANIMATION_TIME);
long newblue = ((long)blue) * diff / (DISTANCE_ANIMATION_TIME + ENERGY_ANIMATION_TIME);
if (newblue < blue)
{
blue = newblue;
}
}
}
// Calculate last disturber fade
unsigned long lastDisturber = detector.getLastDisturber();
unsigned long disturberDiff = timeDifference(now, lastDisturber);
if (cfgMgr.config.disturberBrightness > 0 && lastDisturber != 0 && disturberDiff <= DISTURBER_ANIMATION_TIME)
{
red = (cfgMgr.config.disturberBrightness * (DISTURBER_ANIMATION_TIME - disturberDiff)) / DISTURBER_ANIMATION_TIME;
}
color((limit(white) & 0xFF) << 24 | (limit(red) & 0xFF) << 16 | (limit(green) & 0xFF) << 8 | (limit(blue) & 0xFF));
}
void setup()
{
Serial.begin(115200);
Serial.println("");
cfgMgr.begin();
detector.begin();
neopixel.begin();
neopixel.setBrightness(255);
// Init detector
color(COLOR_CALIBRATING);
Serial.println("Calibrating antenna...");
detector.reset();
unsigned int freq = detector.calibrate();
Serial.print("Calibrated antenna frequency: ");
Serial.print(freq);
Serial.println(" Hz");
color(COLOR_BLACK);
// Set up the detector
setupDetector();
// Start WiFi
WiFi.setSleepMode(WIFI_NONE_SLEEP);
WiFi.mode(WIFI_STA);
connectedEventHandler = WiFi.onStationModeConnected([](const WiFiEventStationModeConnected &event)
{
Serial.print("WiFi connected to: ");
Serial.println(WiFi.SSID());
Serial.print("MAC: ");
Serial.println(WiFi.macAddress()); });
gotIpEventHandler = WiFi.onStationModeGotIP([](const WiFiEventStationModeGotIP &event)
{
Serial.print("IP address: ");
Serial.println(WiFi.localIP());
server.begin();
Serial.print("Server is listening on port: ");
Serial.println(PORT);
connected = true; });
disconnectedEventHandler = WiFi.onStationModeDisconnected([](const WiFiEventStationModeDisconnected &event)
{
connected = false;
Serial.println("WiFi connection lost. Reconnecting...");
WiFi.begin(MY_SSID, MY_PSK); });
WiFi.begin(MY_SSID, MY_PSK);
// Start MDNS
if (MDNS.begin(MY_MDNS_NAME))
{
Serial.println("MDNS responder started");
MDNS.addService("http", "tcp", PORT);
}
// Start server
server.on("/status", handleStatus);
server.on("/settings", handleSettings);
server.on("/update", handleUpdate);
server.on("/calibrate", handleCalibrate);
server.on("/clear", handleClear);
server.on("/reset", handleReset);
server.onNotFound([]()
{ server.send(404, "text/plain", server.uri() + ": not found\n"); });
const char *headerkeys[] = {"X-API-Key"};
server.collectHeaders(headerkeys, sizeof(headerkeys) / sizeof(char *));
}
void loop()
{
const unsigned long now = millis();
if (connected)
{
server.handleClient();
MDNS.update();
#ifdef MY_MQTT_ENABLED
if (!client.loop() && timeDifference(now, beforeMqttConnection) > 1000)
{
beforeMqttConnection = now;
if (client.connect(MY_MQTT_CLIENT_ID, MY_MQTT_USER, MY_MQTT_PASSWORD))
{
Serial.println("Successfully connected to MQTT server");
}
else
{
Serial.print("Connection to MQTT server failed, rc=");
Serial.println(client.state());
}
}
#endif
}
if (detector.update())
{
if (!detector.getLastLightningDetection(0, ledLightning))
{
ledLightning.time = 0;
}
#ifdef MY_MQTT_ENABLED
if (connected && client.connected())
{
sendMqttStatus();
}
#endif
}
if (timeDifference(now, beforeAnimation) > 50)
{
beforeAnimation = now;
updateColor(now);
}
}
.
