now can build. me check in my arduino ide setting compiler wronning is none
error
src\c64enh_font.h:8:9: error: narrowing conversion of '-7' from 'int' to 'uint8_t' {aka 'unsigned char'} [-Wnarrowing]
8 | -7, 8, 32, '~'+1+18, // -width, height, firstChar, lastChar -7, 8, 32, ('~' + 1 + 18),
Change -7 to 249 and fix “error: ‘winding’ was not declared in this scope” As per your advice
And I have one last question I’d like help with.
I added
extra_scripts = post:extra_script.py
platformio.ini
[env:blackpill_f401cc]
platform = ststm32@19.0.0
board = blackpill_f401cc
framework = arduino
lib_deps = waspinator/AccelStepper@^1.64
extra_scripts = post:extra_script.py
post:extra_script.py
Import("env")
# Custom HEX from ELF
env.AddPostAction(
"$BUILD_DIR/${PROGNAME}.elf",
env.VerboseAction(" ".join([
"$OBJCOPY", "-O", "ihex", "-R", ".eeprom",
"$BUILD_DIR/${PROGNAME}.elf", "$BUILD_DIR/${PROGNAME}.hex"
]), "Building $BUILD_DIR/${PROGNAME}.hex")
)
it error
Verbose mode can be enabled via `-v, --verbose` option
CONFIGURATION: https://docs.platformio.org/page/boards/ststm32/blackpill_f401cc.html
PLATFORM: ST STM32 (19.0.0) > WeAct Studio BlackPill V2.0 (STM32F401CC)
HARDWARE: STM32F401CCU6 84MHz, 64KB RAM, 256KB Flash
DEBUG: Current (blackmagic) External (blackmagic, cmsis-dap, jlink, stlink)
PACKAGES:
- framework-arduinoststm32 @ 4.20900.0 (2.9.0)
- framework-cmsis @ 2.50900.0 (5.9.0)
- toolchain-gccarmnoneeabi @ 1.120301.0 (12.3.1)
LDF: Library Dependency Finder -> https://bit.ly/configure-pio-ldf
LDF Modes: Finder ~ chain, Compatibility ~ soft
Found 16 compatible libraries
Scanning dependencies...
Dependency Graph
|-- AccelStepper @ 1.64.0
|-- N5110 SPI LowResource @ 1.0.9
|-- SPI @ 1.1.0
Building in release mode
Linking .pio\build\blackpill_f401cc\firmware.elf
Building C:\Users\ryoda\Documents\PlatformIO\Projects\Coil Winding Machine\.pio\build\blackpill_f401cc/firmware.hex
Usage: arm-none-eabi-objcopy [option(s)] in-file [out-file]
Copies a binary file, possibly transforming it in the process
The options are:
-I --input-target <bfdname> Assume input file is in format <bfdname>
-O --output-target <bfdname> Create an output file in format <bfdname>
-B --binary-architecture <arch> Set output arch, when input is arch-less
-F --target <bfdname> Set both input and output format to <bfdname>
--debugging Convert debugging information, if possible
-p --preserve-dates Copy modified/access timestamps to the output
-D --enable-deterministic-archives
Produce deterministic output when stripping archives
-U --disable-deterministic-archives
Disable -D behavior (default)
-j --only-section <name> Only copy section <name> into the output
--add-gnu-debuglink=<file> Add section .gnu_debuglink linking to <file>
-R --remove-section <name> Remove section <name> from the output
--remove-relocations <name> Remove relocations from section <name>
-S --strip-all Remove all symbol and relocation information
-g --strip-debug Remove all debugging symbols & sections
--strip-dwo Remove all DWO sections
--strip-unneeded Remove all symbols not needed by relocations
-N --strip-symbol <name> Do not copy symbol <name>
--strip-unneeded-symbol <name>
Do not copy symbol <name> unless needed by
relocations
--only-keep-debug Strip everything but the debug information
--extract-dwo Copy only DWO sections
--extract-symbol Remove section contents but keep symbols
--keep-section <name> Do not strip section <name>
-K --keep-symbol <name> Do not strip symbol <name>
--keep-section-symbols Do not strip section symbols
--keep-file-symbols Do not strip file symbol(s)
--localize-hidden Turn all ELF hidden symbols into locals
-L --localize-symbol <name> Force symbol <name> to be marked as a local
--globalize-symbol <name> Force symbol <name> to be marked as a global
-G --keep-global-symbol <name> Localize all symbols except <name>
-W --weaken-symbol <name> Force symbol <name> to be marked as a weak
--weaken Force all global symbols to be marked as weak
-w --wildcard Permit wildcard in symbol comparison
-x --discard-all Remove all non-global symbols
-X --discard-locals Remove any compiler-generated symbols
-i --interleave[=<number>] Only copy N out of every <number> bytes
--interleave-width <number> Set N for --interleave
-b --byte <num> Select byte <num> in every interleaved block
--gap-fill <val> Fill gaps between sections with <val>
--pad-to <addr> Pad the last section up to address <addr>
--set-start <addr> Set the start address to <addr>
{--change-start|--adjust-start} <incr>
Add <incr> to the start address
{--change-addresses|--adjust-vma} <incr>
Add <incr> to LMA, VMA and start addresses
{--change-section-address|--adjust-section-vma} <name>{=|+|-}<val>
Change LMA and VMA of section <name> by <val>
--change-section-lma <name>{=|+|-}<val>
Change the LMA of section <name> by <val>
--change-section-vma <name>{=|+|-}<val>
Change the VMA of section <name> by <val>
{--[no-]change-warnings|--[no-]adjust-warnings}
Warn if a named section does not exist
--set-section-flags <name>=<flags>
Set section <name>'s properties to <flags>
--set-section-alignment <name>=<align>
Set section <name>'s alignment to <align> bytes
--add-section <name>=<file> Add section <name> found in <file> to output
--update-section <name>=<file>
Update contents of section <name> with
contents found in <file>
--dump-section <name>=<file> Dump the contents of section <name> into <file>
--rename-section <old>=<new>[,<flags>] Rename section <old> to <new>
--long-section-names {enable|disable|keep}
Handle long section names in Coff objects.
--change-leading-char Force output format's leading character style
--remove-leading-char Remove leading character from global symbols
--reverse-bytes=<num> Reverse <num> bytes at a time, in output sections with content
--redefine-sym <old>=<new> Redefine symbol name <old> to <new>
--redefine-syms <file> --redefine-sym for all symbol pairs
listed in <file>
--srec-len <number> Restrict the length of generated Srecords
--srec-forceS3 Restrict the type of generated Srecords to S3
--strip-symbols <file> -N for all symbols listed in <file>
--strip-unneeded-symbols <file>
--strip-unneeded-symbol for all symbols listed
in <file>
--keep-symbols <file> -K for all symbols listed in <file>
--localize-symbols <file> -L for all symbols listed in <file>
--globalize-symbols <file> --globalize-symbol for all in <file>
--keep-global-symbols <file> -G for all symbols listed in <file>
--weaken-symbols <file> -W for all symbols listed in <file>
--add-symbol <name>=[<section>:]<value>[,<flags>] Add a symbol
--alt-machine-code <index> Use the target's <index>'th alternative machine
--writable-text Mark the output text as writable
--readonly-text Make the output text write protected
--pure Mark the output file as demand paged
--impure Mark the output file as impure
--prefix-symbols <prefix> Add <prefix> to start of every symbol name
--prefix-sections <prefix> Add <prefix> to start of every section name
--prefix-alloc-sections <prefix>
Add <prefix> to start of every allocatable
section name
--file-alignment <num> Set PE file alignment to <num>
--heap <reserve>[,<commit>] Set PE reserve/commit heap to <reserve>/
<commit>
--image-base <address> Set PE image base to <address>
--section-alignment <num> Set PE section alignment to <num>
--stack <reserve>[,<commit>] Set PE reserve/commit stack to <reserve>/
<commit>
--subsystem <name>[:<version>]
Set PE subsystem to <name> [& <version>]
--compress-debug-sections[={none|zlib|zlib-gnu|zlib-gabi|zstd}]
Compress DWARF debug sections
--decompress-debug-sections Decompress DWARF debug sections using zlib
--elf-stt-common=[yes|no] Generate ELF common symbols with STT_COMMON
type
--verilog-data-width <number> Specifies data width, in bytes, for verilog output
-M --merge-notes Remove redundant entries in note sections
--no-merge-notes Do not attempt to remove redundant notes (default)
-v --verbose List all object files modified
@<file> Read options from <file>
-V --version Display this program's version number
-h --help Display this output
--info List object formats & architectures supported
arm-none-eabi-objcopy: supported targets: elf32-littlearm elf32-littlearm-fdpic elf32-bigarm elf32-bigarm-fdpic elf32-little elf32-big srec symbolsrec verilog tekhex binary ihex plugin
*** [.pio\build\blackpill_f401cc\firmware.elf] Error 1
======================================================================================== [FAILED] Took 3.09 seconds ================================================================================
how to fix
thanks
