How can I define the Espressif API version to use?

,
1

Hello!

In my project with the “esp32cam” board I also use the “ledc” driver.
So far I have chosen the arduino framework, which integrates the Espressif API V4.4.7.

I would like to use the new functions of the API V5.2.2.

What is the best way to proceed?

Thanks for your tips

2

I’m not sure which API is used in the Arduino framework.
I looked at the LEDC sources from API V5.2.2 and learned how to change the pin number for an LEDC channel.

3

Your question is not clear to me.

You’ll find the available Arduino and ESP-IDF versions here

Example:
platform = espressif32 @ 6.7.0:

Arduino - v2.0.16 (based on IDF v4.4.7)

General:
Arduino 2.x is based on ESP-IDF 4.4
Arduino 3.x (not yet available on PlatformIO) will be based on ESP-IDF 5.x

The ESP-IDF version listed in the release notes is for pure ESP-IDF (framework = espidf) or Arduino as Component (framework = espidf, arduino) projects.

4

Thanks for the information.
Would I have found the version of the API used in the settings?

5

You’ll find it in the Changelog:

image896×820 44.4 KB

For the sake of simplicity, I have created a list of the versions.
